Unleash your sprint 200 meters from the finish. Close a gap, fight back, launch a solo attack. The new aero racing machine is made for exactly those moments when it counts. More aerodynamics, more adjustment options, more paths to success.
Integrated aerodynamics: The AeroSystem Shaping, a result of CFD analyses and dynamic wind tunnel tests, optimizes the aerodynamic performance at every yaw angle. The profile's elliptical tube shape provides excellent overall aerodynamics.
Easier Adjustability: All-new cable routing through the handlebar and frame makes it faster and easier to adjust or change cockpit components and fine-tune performance and riding position.
Race-winning Efficiency: The advanced SL Carbon frameset features GIANT's highest quality carbon materials and manufacturing processes. The result is a weight saving of 225 grams compared to the previous generation and an even better stiffness to weight ratio.
-
Frame: Advanced SL carbon frame, 12x142 mm Max. tire clearance: 30mm
-
Fork: Advanced SL full carbon fork, OD Aero steerer tube, 12x100 mm
Product safety information
Manufacturer information:
GIANT Deutschland GmbH
Mettmanner Str. 25
Nordrhein-Westfalen
Erkrath, Deutschland, 40699
https://www.giant-bicycles.com/de/kontakt
https://www.giant-bicycles.com/de
| Rahmengrößen / Sizes |
S, M, M/L, L, XL |
| Rahmen / Frame |
Advanced SL Carbon Frame, 12x142 mm Max.Tire clearance: 30mm |
| Gabel / Fork |
Advanced SL Full carbon fork, OD Aero Fork Shaft, 12x100 mm |
| Innenlager / Bottom Bracket |
BB86 accepts press fit style BB only, bearing set not included |
| Sattelstütze / Seat Post |
Advanced SL Carbon, ISP |
| Zubehör / Accesories |
2x Bottleholder |
| Gewicht / Weight |
1.720 g (Size M, incl. all parts)
|
PLEASE BE AWARE THERE CAN BE CHANGES DUE AVAILABILITY AND OTHER REASONS.
| |
S |
M
|
|
|
|
| Sitzrohrlänge (Mitte - Oberkante) / Seat Tube Length (C-T) (mm) |
710 |
740 |
770 |
800 |
830 |
| Sitzrohrwinkel / Seat Angle |
74° |
73,5° |
73° |
73° |
72,5° |
| Steurohrlänge / Headtube Length (mm) |
130 |
145 |
165 |
185 |
200 |
| Steurohrwinkel / Head Angle |
72,3° |
73° |
73° |
73° |
73° |
| Oberrohrlänge / Top Tube Length (mm) |
535 |
550 |
565 |
580 |
600 |
| BB Drop |
70 |
70 |
67 |
67 |
67 |
| Kettenstrebenlänge / Chain Stay Length (mm) |
405 |
405 |
405 |
405 |
405 |
| Gabelvorbiegung / Fork Rake (mm) |
45 |
45 |
45 |
45 |
45 |
| Gabelnachlauf / Trail (mm) |
62,5 |
57,8 |
57,8 |
57,8 |
57,8 |
| Radstand / Wheelbase (mm) |
977 |
980 |
991 |
1006 |
1020 |
| Überstandshöhe / Standover (mm) |
755 |
775 |
794 |
821 |
834 |
| Reach (mm) |
383 |
388 |
393 |
402 |
412 |
| Stack (mm) |
528 |
545 |
562 |
581 |
596 |
| Vorbaulänge / Stem Length (mm) |
90 |
100 |
110 |
110 |
120 |
| Kurbellänge / Crank Arm Length (mm) |
170 |
172,5 |
172,5 |
175 |
175 |
| Lenkerbreite / Handlebar Width (dropcenter - Center) (mm) |
400 |
420 |
420 |
440 |
440 |
Alle Angaben in mm sofern nicht anders angegeben / All measurements in mm unless otherwise stated
Irrtümer vorbhalten / Errors excepted
