If you only have room for one bike in your life, Straggler can (and should) be your one and only.
A decade-long hiatus taught us there’s more work to be done when it comes to resplendent riding on unpaved terrain. Thus, the new Straggler emerges with a dialed-in fit range and comfortable geometry, ready to roll with thru-axle wheels, flat-mount brakes, and zero ego.
It's a bike down for a lot of stuff, but it really shines when it’s kicking up dust to help you blow off some steam and get back to those dirt roots. No more missed opportunities or dead ends –– the Straggler’s taking every rowdy detour or weekend rendezvous it can get. It’s the ultimate day-tripper, cross-terrain explorer, and boundary-pusher, ready for you to plow through challenges, not obstacles.
Straggler’s capabilities extend into some light cargo setups, so you can do double-duty when hitting the trails and running around town. Tack on one of our Pack Racks and maybe a frame bag when you need to grab some groceries on the way back to civilization –– knowing with Straggler, you always have an Exit plan.
- 650b or 700c wheels (varies by frame size) for optimized rider fit
- Racks and fender mounts, plus two standard and one three-pack bottle mounts on all frames
- Updated thru-axle dropouts for improved stiffness and handling
- Modern flat-mount brake mounts, internal dropper routing, and 44mm headtube
- Lower bottom bracket and sloping top tube adds stability and better standover
- 50mm tire clearance w/o fenders on 700c for confident, comfortable riding on eroded terrain
tech specifications
- Frame Construction 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
- Fork Construction 4130 Chromoly, Natch tubing, TIG welded, brazed lugs, E.D. coated
- Suspension Fork Length (Travel) 436 x 51mm (40mm)
- Fork Offset 44mm
- Axle to Crown 650b (Size 46–52): 390mm 700c (Size 54–64): 410mm
- Rear Spacing 12 x 142mm (Axle included)
- Front Brake (Rotor) Disc - Flat Mount Fork 140/160 (160mm max)
- Headset - Upper ZS44/28.6
- Headset - Lower EC44/30
- Front Spacing 12 x 100mm (Axle included) Steerer Tube Ø28.6mm (1-1/8")
- Crown Race Ø30mm (1-1/8") Stem Clamp Ø28.6mm (1-1/8") Seatpost Ø27.2mm
- Dropper Post Compatible Yes, Internal
- Seatpost Clamp Ø30mm
- Front Derailleur Clamp High band clamp or braze-on with adapter bottom-pull (Ø28.6mm) 47CL
- Bottom Bracket 68mm threaded (1.37" x 24TPI)
- Crankset (Max Ring) Single ring, 47mm chainline crankset: 46T Double, 47mm chainline crankset: 50/34T
- Bottle Mounts 2 Standard + 1 Three-Pack Fork Mounts Rack mounts: upper, lower, and mid-blade threaded
- Front Fender Mounts Yes
- Rear Fender Mounts Yes
- tire clearance: 700 x 50 mm (w/o Fender), 700 x 47 (with Fender), 650b x 50 mm (with Fender)
Product safety information
Manufacturer information:
Surly Bikes
6400 W 105th Street
Minnesota
Bloomington, Vereinigte Staaten, 55438
derby@surlybikes.com
https://www.surlybikes.com
Responsible person:
Cosmic Sports GmbH
Leyher Str. 47
Bayern
Fürth, Deutschland, 90763
info@cosmicsports.de
https://www.cosmicsports.de
| |
54
|
|
|
|
62 |
| Sitzrohrlänge / Seat Tube Length (C-Top Top Tube) |
490 |
520 |
545 |
570 |
620 |
| Oberrohrlänge / Top Tube Length (effective) |
555 |
570 |
585 |
605 |
630 |
| Sitzrohrwinkel (°) / Seat Angle |
74° |
73° |
72,5° |
72,5° |
72,5° |
| Steuerohrwinkel / Head Angle (°) |
71,5° |
72° |
72° |
72° |
72° |
| Steuerohrlänge / Headtube Length |
120 |
140 |
160 |
190 |
220 |
| BB Drop |
72 |
72 |
72 |
72 |
72 |
| Kettenstrebenlänge / Chain Stay Length |
435 |
435 |
435 |
435 |
435 |
| Gabelvorbiegung / Fork Offset |
44 |
44 |
44 |
44 |
44 |
| Radstand / Wheelbase |
1033,6 |
1033,2 |
1042,7 |
1063 |
1088,3 |
| Überstandshöhe / Standover |
779 |
807 |
830 |
857 |
895 |
| Reach |
391,4 |
389,1 |
392,5 |
403,5 |
419,5 |
| Stack |
570,7 |
591,6 |
610,6 |
639,1 |
667,7 |
| empfohlene Fahrergröße / Recommended Rider height (cm) |
166-177 |
173-183 |
179-189 |
184-194 |
193-203 |
Alle Angaben in mm sofern nicht anders angegeben / All measurements in mm unless otherwise stated
Irrtümer vorbehalten / Errors excepted
