Stylish, robust, and easy to maintain – these are White Industries' goals when developing headsets. The logos are machine-engraved, giving them a premium look. White Industries uses durable and easily replaceable stainless steel enduro angular contact bearings and a split crown race design that can be installed and removed by hand.
The EC34|EC44 headset is designed for frames with tapered head tubes (34 mm top/44 mm bottom) and, with the appropriate crown race, can accommodate both straight and tapered fork steerers. Please refer to the SHIS specifications below. SHIS? Exactly, that's the "Standardized Headset Identification System" (SCS), which is used to verify compatibility.
Technical Specifications:
- Material: 6061-T6 Aluminum
- Machine-engraved logos
- Easily replaceable stainless steel enduro angular contact ball bearings
- Split crown race for tool-free installation and removal
- Upper crown race height: 15 mm
- Lower crown race height: 12 mm
- Star nuts are not included Included!
Compatibility:
The EC34│EC44 headset is suitable for frames with tapered 34 mm/44 mm head tubes and three different steerer tube types. "EC" stands for "External Cup." This means that the part of the bearing cup that holds the bearing sits outside the head tube. "34" refers to the 34 mm steerer tube, which is pressed into the top of the head tube, and "44" refers to the 44 mm steerer tube, which is pressed into the top of the head tube. for the 44 mm steerer tube, which is pressed into the bottom of the head tube.
SHIS Specification:
- Upper: EC34/28.6
- Lower: EC44/30, EC44/33, or EC4440
- Compatible with 3 steerer tube types:
- Straight 1-1/8" with 30 mm crown race
- Tapered 1-1/4" with 33 mm crown race
- Tapered 1-1/2" with 40 mm crown race
- Not compatible with carbon forks with integrated crown race
- Inner diameter of upper steerer tube: 33.9 mm to 33.95 mm
- Inner diameter of lower steerer tube: 43.95 mm to 44 mm
- Upper steerer tube diameter: 28.45 mm to 28.6 mm
- Crown race diameter for straight 1-1/8": 30.015 mm to 30.075 mm
- Crown race diameter for tapered 1-1/4": 33.03 mm to 30.09 mm
- Crown race diameter for tapered 1-1/2: 39.79mm to 39.85mm
